Volume

Accumulator volume (L）

1.5X2

Extrusion system

Screw diameter（mm）

Φ65X2

Screw L/D

25

Plasticizing capacity ( kg / h )

 55( HDPE )X2

Heating zone of barrel

4

Heating power of barrel ( KW )

12X2

Extrusion motor power ( KW )

22X2

Die head

Max storing volume ( L )

1.5X2

Max shooting material speed ( kg / sec. )

1X2

Die mouth diameter ( mm )

15-80

parison thickness control points

100

Heating zone of die head

4+4

Heating power of die head ( KW )

37

Clamping device

Dimension of mould plate（WxH） ( mm )

900x800

Distance between of mould platens ( mm )

400-1050

Clamping force ( KN )

200

Take-out device

Take-out stroke ( mm )

850

Clamping stroke ( mm )

150

Frame ware

Lifting speed (mm / min.)

30

Lifting stroke ( mm )

600

Hydraulic system

 Rated hydraulic pressure ( MPa )

12

Rated  hydraulic pressure of small pump( Mpa. )

16

Rated flow of small pump (L / min.  )

25

 Hydraulic pump motor power ( KW )

30

Hydraulic servo system of parison thickness controller

Rated pressure (MPa )

12

Rated flow (L / min.)

116

Motor power of hydraulic pump ( KW )

18.5

Pneumatic system

Air source pressure ( MPa )

1.2

Working pressure ( MPa )

1.0

Air consumption (M3 / min.)

1

Water supply

Pressure ( MPa )

0.3

Power supply

Voltage

AC380V±10%

Frequency

50HZ

Connection

3 phase 4 wires

Total rated power ( KW )

165

Average consumption ( KW/ h )

65

Weight (Ton.)

32

machine dimension（Lx W x H ） ( m )

6.3x4x4.4
